Soft Wheel
Soft Wheel
Type：Soft WheelProduct Details
| Wheel material: | Nylon / PU (rim) |
| Top fittings: | Socket Stem (Grip neck) |
|
Friction Ring |
|
|
Thread Stem |
|
| Swivel Plate | |
| U-Clip Stem | |
| Lead-time: | 45-60 day |
| MOQ: | 5,000 pcs |
Specification
| Part No. | Wheel Diameter |
Wheel Width |
Wheel Height |
Dynamic Loading Capacity | Static Loading Capacity | Brake Type |
| UTWPU40 | 40MM | 39.0MM | 20kgs (44lbs) | 25kgs (55lbs) |
No Brake |
|
| Part No. | Wheel Diameter | Wheel Width | Wheel Height | Dynamic Loading Capacity | Static Loading Capacity |
Brake Type |
| UTWPU50 | 50MM | 43.8MM | 30kgs (66lbs) | 35kgs (77lbs) |
No Brake |
|
| UTWBPU50 | 50MM | 43.8MM | 30kgs (66lbs) | 35kgs (77lbs) |
Brake |
|
| Part No. | Wheel Diameter | Wheel Width | Wheel Height | Dynamic Loading Capacity | Static Loading Capacity |
Brake Type |
| UTWPU60 | 60MM | 58.0MM | 68.5MM | 60kgs (132lbs) | 80kgs (176lbs) |
No Brake |
| UTWBPU60 | 60MM | 58.0MM | 68.5MM | 60kgs (132lbs) | 80kgs (176lbs) | Brake |
| Part No. | Wheel Diameter | Wheel Width | Wheel Height | Dynamic Loading Capacity | Static Loading Capacity | Brake Type |
| UTWPU75 | 73MM | 63.0MM | 81MM | 60kgs (132lbs) | 80kgs (176lbs) | No Brake |
| UTWBPU75 | 73MM | 63.0MM | 81MM | 60kgs (132lbs) | 80kgs (176lbs) | Brake |
| Part No. | Wheel Diameter | Wheel Width | Wheel Height | Dynamic Loading Capacity | Static Loading Capacity | Brake Type |
| UTWPU100 | 100MM | 73.5MM | 108MM | 80kgs (176lbs) | 100kgs (220lbs) | No Brake |
| UTWBPU100 | 100MM | 73.5MM | 108MM | 80kgs (176lbs) | 100kgs (220lbs) | Brake |
| Part No. | Wheel Diameter | Wheel Width | Wheel Height | Dynamic Loading Capacity | Static Loading Capacity | Brake Type |
| UTWPU125 | 125MM | 86.5MM | 138MM | 100kgs (220lbs) | 120kgs (264lbs) | No Brake |
| UTWBPU125 | 125MM | 86.5MM | 138MM | 100kgs (220lbs) | 120kgs (264lbs) | Brake |
Product Inquiry
Feel free to add the products you're interested in to your inquiry list. Based on your specifications, we’ll provide a complete quotation and tailored recommendations.
